"I want a square G-SHOCK, but I cannot picture its size or weight."
To help solve that problem, this article brings the key models' thickness, weight, height and width, and lug width together in a single quick-reference table.
Use this article to assess wearing comfort; for parts interchangeability, see the companion Comprehensive Compatibility Guide.
Models Covered and Overview
Where to Buy the Casio GW-5000U-1
Affiliate links — we may earn a commission.
This article compares dimensions that directly affect wearing comfort across the main square G-SHOCK families.
It reconciles published specifications with available measurements, focusing on relative comparisons within each category.
| Family | Representative model | Features |
|---|---|---|
| 5000 family | GW-5000U | A screw-back case gives it a stable center of gravity. A classic choice. |
| 5600 family | DW-5600UE | Light and thin, ideal for everyday use. A standard entry-level choice. |
| 5610 family | GW-M5610U / GW-M5610UBC | Solar with radio-controlled timekeeping, balancing thinness and legibility. |
| Full-metal family | GMW-B5000D | Substantial and premium; heavier, but highly satisfying. |
| For reference2100 family | GM-B2100D / GMC-B2100D | Octagonal analog models, included as a reference for comparing wearing comfort. |
Note: Detailed parts compatibility is covered in the Comprehensive Square G-SHOCK Compatibility Guide.
Size Comparison: Key Models
The DW-5600 and GW-M5610 are the lightest.
Where to Buy the Casio DW-5600UE-1
Affiliate links — we may earn a commission.
Start by Comparing Thickness, Height × Width, and Weight Together.
| Model | Family | Thickness (mm) | Height × width (mm) | Weight (g) | Notes |
|---|---|---|---|---|---|
| GA-2100-1A1 | 2100, for reference | 11.8 | 48.5 × 45.4 | 51g | Thinnest and lightest |
| DW-5600UE | 5600 | 13.4 | 48.9 × 42.8 | 52g | Among the lightest. A benchmark for everyday use. |
| GW-M5610U | 5610 | 12.7 | 46.7 × 43.2 | 52g | Among the lightest. A classic slim model with solar power and radio-controlled timekeeping. |
| GW-5000U | 5000 | 13.2 | 48.9 × 42.8 | 74g | Screw-back case; slightly heavier. |
| GW-B5600 | 5600 | 13.4 | 48.9 × 42.8 | 53g | Bluetooth-equipped model. |
| GW-M5610UBC | 5610 | 12.7 | 46.7 × 43.2 | ※101g Varies with band-length adjustment | Comfortable composite band with three-fold clasp. |
| GMW-B5000D | Full metal | 13.0 | 49.3 × 43.2 | ※167g Varies with band-length adjustment | Substantial, but surprisingly thin. |
| GMW-B5000GD | Full metal | 13.0 | 49.3 × 43.2 | ※167g Varies with band-length adjustment | Gold finish. |
| DWE-5657RE | For reference5700 | 13.7 | 48.9 × 42.8 | 58g | Includes a round bezel for swapping. |
| GM-B2100D | For reference2100 | 12.8 | 49.8 × 44.4 | ※165g Varies with band-length adjustment | Full-metal octagon, for reference. |
| GMC-B2100D | For reference2100 | 13.0 | 49.9 × 44.4 | ※170g Varies with band-length adjustment | All-analog flagship. |
Note: Figures are primarily published specifications; some vary due to measurement or specification differences.
Weight changes considerably with resin, composite, or metal bands.
Where to Buy the Casio GW-M5610U-1
Affiliate links — we may earn a commission.
The GA-2100 is thinner and lighter still.
Where to Buy the Casio GA-2100-1A1
Affiliate links — we may earn a commission.
Ranking by Thinness: Choosing for Sleeve Clearance
- GW-M5610U / UBC：12.7mm… Among the thinnest, unlikely to interfere with suit cuffs.
- GMW-B5000D / GD：13.0mm… Surprisingly thin even in metal; heavy, but good sleeve clearance.
- GW-5000U：13.2mm, DW-5600UE：13.4mm… Standard thickness for comfortable daily use.
A thickness guideline for fitting under cuffs:
If you want it to fit under a suit or shirt cuff comfortably, use up to approximately 13.5mm as a general benchmark.
The GW-M5610U/UBC and GMW-B5000 meet it.
Where to Buy the Casio GW-M5610UBC-1
Affiliate links — we may earn a commission.
Where to Buy a Genuine Casio Band for GW-M5600BC and GW-M5610BC
Affiliate links — we may earn a commission.
Ranking by Lightness: Choosing to Reduce Fatigue
The DW-5600 and GW-M5610 are the lightest and are recommended.
| Rank | Model | Weight | Comments |
|---|---|---|---|
| ① | DW-5600UE | Approximately 52g | Light and easy to handle. Suitable for almost anyone. |
| ② | GW-M5610U | Approximately 52g | Light even with solar power and radio-controlled timekeeping. |
| ③ | GW-5000U | Approximately 74g | The center of gravity characteristic of a screw-back case gives a stable feel. |
| ④ | GMW-B5000D / GD | Approximately 167g | Prioritizes substance, with the satisfying feel of a metal bracelet. |
Where to Buy the Casio DW-5600UE-1
Affiliate links — we may earn a commission.
Where to Buy a Screen Protector for Casio DW-5600
Affiliate links — we may earn a commission.
Where to Buy the Casio DW-5600RL-1
Affiliate links — we may earn a commission.
Where to Buy the Casio GW-M5610U-1
Affiliate links — we may earn a commission.
Recommendations by Wrist Size
I recommend the GMW-B5000D, whose band can be freely adjusted.
Where to Buy the Casio GMW-B5000D-1
Affiliate links — we may earn a commission.
Where to Buy the Casio GMW-B5000GD-9
Affiliate links — we may earn a commission.
| Approximate wrist circumference | Recommended models | Selection tips |
|---|---|---|
| 〜15cm | GW-M5610U / DW-5600UE | Compact and thin for an excellent fit; a resin band is recommended. |
| 15〜17cm | GW-5000U / GW-B5600 | A versatile standard size; a composite band is comfortable too. |
| 17cm〜 | GMW-B5000D / GD | Heavier but distinctly premium; bracelet adjustment helps it sit well. |
| 17.5cm〜 | GM-B2100D / GMC-B2100D | An octagonal metal watch with presence, modest thickness, and good sleeve clearance. |
Choosing by Appearance and Use
The DW-5000R re-creation of the original is popular.
Where to Buy the Casio DW-5000R-1A
Affiliate links — we may earn a commission.
- For a Subtle Business Look: GW-M5610U / GW-5000U: black, thin, and easy-to-read dials
- For Sweat and Outdoor Use: GW-B5600BC: composite-band comfort
- For Weekend Satisfaction: GMW-B5000D / GD: metal presence and finish
Size and Compatibility: A Caution
Even when sizes are similar, different bezel or band mounting structures—tabs, button holes, or lug shapes—prevent swapping.
Use this article for wearing comfort and the Compatibility Guide for parts interchangeability.
For example, GW-M5610U and GW-B5600 have similar dimensions, but my hands-on tests showed no bezel compatibility, with gaps or lifting when fitted.
The basics of band types are covered in 3 Interchangeable Band Types .
Size Selection FAQ
I would also like to own the top-tier MRG-B5000B someday, although it is very difficult to obtain.
Where to Buy the Casio MRG-B5000B-1JR
Affiliate links — we may earn a commission.
Q. What Thickness Is a Useful Guide for Fitting Under Suit Cuffs?
A. Individual results vary, but 〜13.5mm is a useful benchmark. GW-M5610U / UBC are leading candidates.
Q. Which Model Should I Choose if Lightness Comes First?
A. With a resin band, the DW-5600UE / GW-M5610U is light at approximately 52g.
Q. Which Metal Model Has Good Sleeve Clearance?
A. GMW-B5000 is surprisingly thin at approximately 13.0mm and works well with shirts.
Conclusion: Understanding the Numbers Helps You Choose
- Compact and Light: DW-5600UE / GW-M5610U
- Standard and Versatile: GW-5000U / GW-B5600
- Premium Feel and Satisfaction: GMW-B5000D / GD and, for reference, GM-B2100D / GMC-B2100D
If you are unsure about wearing comfort, compare thickness, height and width, and weight along 3 dimensions.
Once you find the best fit, check compatibility and band types to make it a comfortable watch for you.
